Shelter Modena p95

Modena p95 shelter

The Modena p95 shelter for bus stops features a cantilevered design offering exceptional durability and functionality.

Creative design and advanced functionality
Made up of 4 vertical uprights in galvanized steel round tube; each single upright is complete with a base plate in galvanized sheet metal. 2 lateral arches, in the upper part, in galvanized steel round tube; the arches are connected and made integral with each other by 2 galvanized steel rectangular tube currents (rear and front part). Back wall made up of frames in galvanized steel profiles. Transparent laminated glass with polished edge, inserted into the frame with special gaskets and glass holder in galvanized steel angular profile. Side walls made up of frames in galvanized steel profiles. Transparent laminated glass with polished edge, inserted into the frame with special perimeter gaskets and supported by a glass holder in galvanized steel corner profile. Vault-type roofing made of smoked honeycomb polycarbonate supported by arches in galvanized steel rectangular tube. Side gables in transparent compact polycarbonate, shatterproof, protected from UV rays and particularly suitable for outdoor use. No. 4 strips along the perimeter of the roofing, in galvanized sheet metal to affix the name of the stop, if applicable.

Technical features
  •  Rainwater drainage: Gutter, in the front, for collecting and draining rainwater.
  •  Bench: Bench consisting of N. 2 supports in round tube of galvanized steel provided with plates at the base in galvanized sheet metal. N. 1 stiffening arch in rectangular tube of galvanized steel. Seat composed of N. 6 profiles in oval section galvanized steel tube complete with end caps.
  •  Noticeboard: N. 1 noticeboard (left side front view) in galvanized steel box with book-style opening door, made of galvanized steel profiles and key lock (universal key). Reading side in transparent compact polycarbonate, shatterproof, protected from UV rays and particularly suitable for outdoor use. Posting of notices or other communications using magnets.

Request more information
To discover all the technical details of the product, you can download the detailed technical sheet.

The Modena p95 shelter is also available on the "acquistinretepa - MEPA" portal by searching for the code DIMCAR311 "in product codes"

If you would like a personalized quote or a custom finish, contact us today!
