Shelter Barocco

Baroque Shelter
A furnishing solution designed to offer a comfortable shelter to users waiting for the bus, combining functionality and elegance in a refined design.

Creative design and advanced functionality
Made up of N. 3 rear uprights made of galvanized steel profile with a rounded corner (side uprights) and in galvanized steel square tube (central upright). Each single upright is complete with a base plate in galvanized sheet metal with holes for fixing to the ground. N. 2 front uprights in galvanized steel round tube (lower and upper part), with decorative intermediate element in turned steel; each single upright is complete with flange at the base. Covering frame made up of N. 2 lateral ribs in galvanized sheet metal. The ribs are connected and made integral with each other by a boxed profile (upper part), a cantilevered shaped profile (front part) and a frame in rectangular galvanized steel tube. Side and rear walls made of a perimeter frame in angular galvanized steel profile complete with decorative crosspieces on the external part, in square galvanized steel tube.

Technical features
  •  Infill: Infill in transparent honeycomb polycarbonate supported by profiles in rectangular galvanized steel tube.
  •  Rainwater drainage: Covering made of galvanized sheet metal, equipped with a gutter at the rear for collecting and draining rainwater.
  •  Bench: Bench made of N. 2 supports in round tube of galvanized steel; seat made with N. 5 profiles in oval section galvanized steel tube complete with PVC end caps.
  • Safe Anchoring: Designed for fixing via brackets and template, preventing tipping and unwanted movements.


Customization and Resistance for every environment
To adapt to different aesthetic needs, the shelter is available in the basic finish "gunmetal". Furthermore, upon request it is possible to request customized colors and finishes to integrate the shelter perfectly into the surrounding environment. The structure, made of galvanized steel and painted with thermosetting powders, guarantees high resistance to atmospheric agents and a long life over time.

Request more information
To discover all the technical details of the product, you can download the detailed technical sheet.

The Barocco shelter is also available on the "acquistinretepa - MEPA" portal by searching for the code DIMCAR282 "in product codes"

If you would like a personalized quote or a custom finish, contact us today!
